10’X22″METAL LATHE

Description

10″ X 22″ Metal Lathe- Powerful 1 HP Motor- Safety guard with limit switch protection- Line interruption switch system needs a restart after a power failure- Guideway and gears in headstock are all hardened and precision ground- Comes complete with 5″-3 jaw chuck, 6-1/2″-4 jaw chuck, imperial and metric gears, 4 ways tool post, steady rest, follow rest, 8″ face plate, thread chasing dial indicator, MT3 dead center, full length splash guard, tool box, chuck key and hex.l keysDistance Between Centers = 22″Swing Over Bed = 10″Spindle Bore = 1″Swing Over Cross Slide = 6″Taper in headstock = MT 4Taper in tailstock = MT 3Width Of Bedways = 6″Total Travel Of Cross Slide = 6-3/8″Total Travel Of Top Slide = 4-1/4″Spindle Speeds = 6 (150-2,400) RPMThread Cutting = 24 (8-72 TPI) 18 (.25-3mm)Motor = 12 Amp.Voltage = 110V, 1 phase, 60 HzAssembled dimensions (LxWxH) = 50″ x 23″ x 19″ / 360 lbsPackage Dimensions (LxWxH) = 49″ x 26-3/8″ x 21-3/8″ / 440 lbs
