Conversion Wheel Hub Adapter For 3-Bolt Chinese Rims with 90mm Bolt Circle

Description

Product Specs:

• Brand: BMI Karts
• Material: Aluminum
• Bolt Pattern to Chinese Rim: (3) 5/16-24 Threaded Bolt Holes on a 90mm (3.54″) Bolt Circle
• Bolt to Bolt Measurement: 3.07″ (78mm)
• Outside Diameter: 4.2″
• Includes Bolts and Nuts

Bolt Circle Option for Wheel Hub

• (3) 5/16″ Holes on a 2-1/2″ Bolt Circle (American Racing Wheel Hub Pattern)
• (3) 8mm Holes on a 58mm Bolt Circle (Metric Racing Wheel Hub Pattern)

Features:

• This part can be interchangeable with many ATVs, Quads, or Go Karts from manufactures including TaoTao, Coolster, Sunl, Kandi, Lynx Models. Please check with the manufacture to see if this part will fit your model.
• Chinese commonly use a 145/70-6 Tire with Rim with a 3-bolt pattern, similar to below. This wheel hub adapter allows you to utilizes this tire and rim combo with our racing wheel hubs. Giving you the option to use this tire and rim with standard 5/8″ spindles or 3/4″, 1″ or 1-1/4″ live axles. Note: To use this on a 1/2″ or 3/4″ spindle, only requires a bearing change in the hub.
